HP MSA 1040 2-port 10G iSCSI Dual Controller LFF Storage

Part № : E7W03A

RENEW Part № : E7W03AR

Availability : Call

  • Description
  • Specification
The HPE MSA 1040 Storage is designed for entry-level market needs, features 8Gb Fibre Channel, 12 Gb SAS, and 1GbE and 10GbE iSCSI at previously unattainable entry price points. The array allows users to take advantage of the latest storage technologies in simple and efficient ways by providing a good balance between performance and budget resulting in a highly favorable $/GB return on their investment. Entry consolidation and virtualization initiatives are now well in your budgetary reach. The MSA 1040 offers many of MSA 2040 features but at more affordable entry price point. ProLiant and BladeSystems administrators as well as IT generalists will find storage management tasks simple and intuitive with MSA. The MSA 1040 arrays leverage a new 4th-generation MSA architecture with a new processor, 2-host ports and 4GB data cache and 2GB of system memory per controller. Take advantage of the latest hard drive advances by choosing the form factor and technology which best meets your application and budget requirements. Unlike many competing arrays, the MSA 1040 ships standard with intuitive management tools and powerful data services such as Snapshots and Volume Copy for increased data protection. The MSA1040 now offers a simplified licensing strategy with one optional software suite. The Advanced Data Services Suite include the following software licenses: - HPE MSA 2042 Performance Automated Tiering LTU - HPE MSA 512-Snapshot Software LTU - HPE MSA Remote Snap Software LTU

QuickSpecs

HPE Quickspecs Open Link

Generic

Capacity 120 TB (single LFF array-head -using 12 x 10TB LFF SAS MDL drives) 480 TB (by adding 3 LFF Disk Enclosures behind LFF Array & using 10 TB LFF SAS MDL drives)
Pool Capacity GL200: 169 TB (154 TiB)
GL210: 219 TB (200 TiB)
GL220: 329 TB (300 TiB)
GL220 with Large Pool Support: 562 TB (512 TiB)
Cache 6 GB per controller
Total LUNs 512 maximum LUN size: 140TB (128TiB) Thin Provisioning allows you to create the LUNs independent of the physical storage
Host Interconnect 2 x 10GbE ports per controller
Maximum Drives 48 LFF
Maximum Host Supported 64 in v2 UI 512 in v3 UI
Standard Software Snapshots (64)
Optional Software Remote Snap (linear storage only) Max Snapshot (512)
