| I/O ports and slots | 48 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T,
IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T);
Duplex:
10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only |
| Additional ports and slots | 1 RJ-45 console port to access limited
CLI port |
| Physical
characteristics |
| Dimensions |
17.32(w) x 9.37(d) x 1.73(h) in (43.99 x
23.8 x 4.39 cm) |
| Weight |
7.28 lb (3.3 kg) |
|
| Memory and processor | MIPS @ 650 MHz, 32 MB flash, 128 MB
SDRAM; packet buffer size: 12 Mb |
| Mounting and enclosure | Mounts in an EIA standard 19-inch
telco rack or equipment cabinet
(hardware included) |
| Performance |
| 100 Mb Latency |
< 7 µs |
| 1000 Mb Latency |
< 5 µs up to 71 |
| Throughput |
up to 71.4 Mpps (64-byte packets) |
| Routing/Switching capacity |
96 Gbps |
| MAC address table size |
16384 entries |
|
| Reliability | |
| Environment |
| Operating temperature |
32°F to 104°F (0°C to 40°C) |
| Operating relative humidity |
5% to 95%, noncondensing |
| Non-operating/Storage temperature |
-40°F to 158°F (-40°C to 70°C) |
| Non-operating/Storage relative humidity |
5% to 95%, noncondensing |
| Altitude |
up to 16,404 ft (5 km) |
| Acoustic |
Power: 49.7 dB, Pressure: 49.7 dB;
ISO 7779 |
|
| Electrical characteristics |
| Frequency |
50/60 Hz |
| Voltage |
100-240 VAC |
| Maximum power rating |
90 W |
|
| Safety | IEC 60950-1; EN 60950-1; CSA 22.2
60950-1; UL 60950-1 2nd Edition |
| Emissions | FCC part 15 Class A; VCCI Class A; EN
55022 Class A; CISPR 22 Class A; EN
55024; EN 61000-3-2 2000, 61000-
3-3; ICES-003 Class A |
| Services | Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for
details on the service-level descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise sales office |
| |
