I/O ports and slots | 24 RJ-45 auto-negotiating 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3af PoE, IEEE 802.3at)
2 SFP+ fixed 1000/10000 SFP+ ports
2 RJ-45 1/10GBASE-T ports |
Additional ports and slots | 1 RJ-45 console port to access limited CLI port |
Physical
characteristics |
Dimensions |
17.32(w) x 14.17(d) x 1.73(h) in (44 x 36 x 4.4 cm) (1U height) |
Weight |
13.23 lb (6 kg) |
|
Memory and processor | 128 MB flash; Packet buffer size: 3 MB, 1 GB SDRAM |
Mounting and enclosure | Mounts in an EIA standard 19-inch telco rack or equipment cabinet (hardware included) |
Performance |
100 Mb Latency |
< 5 µs |
1000 Mb Latency |
< 5 µs |
10 Gbps Latency |
< 1.5 µs |
Throughput |
up to 95.2 Mpps (64-byte packets) |
Routing/Switching capacity |
128 Gbps |
Routing table size |
32 entries (IPv4), 32 entries (IPv6) |
MAC address table size |
16384 entries |
|
Reliability | |
Environment |
Operating temperature |
32°F to 113°F (0°C to 45°C) |
Operating relative humidity |
10% to 90%, noncondensing |
Non-operating/Storage temperature |
-40°F to 158°F (-40°C to 70°C) |
Non-operating/Storage relative humidity |
5% to 95%, noncondensing |
Altitude |
up to 16,404 ft (5 km) |
Acoustic |
Low-speed fan: 37.3 dB, High-speed fan: 47.1 dB; ISO 7779 Dual speed fan
|
|
Electrical characteristics |
Frequency |
50/60 Hz |
Voltage |
100 - 240 VAC, rated |
Maximum power rating |
425 W |
PoE power |
370 W PoE+ |
|
Safety | UL 60950; IEC 60950-1; EN 60950-1; GB 4943.1 |
Emissions | FCC part 15 Class A; VCCI Class A; EN 55022 Class A; CISPR 22 Class A; EN 55024; EN 61000-3-2
2000, 61000-3-3; ICES-003 Class A |
Management | IMC - Intelligent Management Center; Limited command-line interface; Web browser; SNMP manager;
HTTPS; RMON1; FTP; Supported by HP IMC and generic SNMP management platforms. Refer to
documentation for MIB support details. |
Services | Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for
details on the service-level descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise sales office |
| |
